Uflex UP28R Rear Mount Helm 1.7 cu. 3/4
Uflex USA

Uflex UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft [UP28R]

SKU: C-75560 In stock
Quantity:

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft

Features:

  • Available in four different displacement sizes
  • Compact design
  • Ball bearing piston race
  • Built-in lock valve for positive rudder lock
  • Integral relief valve for over-pressure protection
  • 3/4” tapered stainless steel shaft
  • Easily accessible lock valve and shaft seal for replacement
  • Cast iron cylinder rotor for greater durability and longer life
  • 1/4" NPT fitting for 3/8" tube
  • Includes 90° adjustable fittings for 3/8” tube and white bezel
  • UP45R pump is ideal for double cylinder outboard applications
  • UP45 pump is available also for inboard application
  • X68 (optional) - 40894Z Chrome bezel
  • KITF (optional) - 39664Y Remote fill adapter

Specifications:

  • Mounting: Retro-cruscotto
  • Displacement/Revolution: 28 cc-1.7 cu in
  • # of Pistons: 5
  • Relief Valve Setting: 70 Bar - 1000 PSI
  • Maximum Wheel Diameter: 710mm - 28"
  • Weight: 5kg - 11 lbs.
